Freestyle 2 Handheld Scanner

—

Lorem ipsum dolor sit amet.

Request

The FARO Freestyle 2 is a superior handheld 3D scanner designed for professionals who require quick and easy complete scene documentation. Delivering fast, photorealistic 3D reality capture with unparalleled real-time display results, Freestyle 2 offers total mobility to scan even the most confined spaces and difficult objects.Use AnywhereWith its light weight, cable-free design and six degrees of freedom, you can operate the Freestyle 2 with one hand anywhere, at any angle — even upside down.



Description

  • Real-Time Visualization

Display lets you view what you capture as you scan

  • Scan from Nearly Any Distance

With a best-in-class range of .4m to 5m (1.3′- 16′), the Freestyle 2 captures small and large areas.

  • Quickly Capture Photorealistic Detail

It takes just a few minutes to capture amazing detail and quality.

  • No Annual Calibration Required

Use this self-contained solution with confidence.
Tech Sheet
Performance Specifications
Range 0.4 – 5 m (up to 10 m with limited data quality)
Identifiable feature Up to 0.2 mm
3D point accuracy1 ≤0.5 mm
Long range accuracy2 0.5 mm at 1 m distance 5 mm at 5 m distance 15 mm at 10 m distance
Single image point density Up to 45,000 points/m2 in 0.5 m distance Up to 10,500 points/m2 in 1 m distance
Acquisition Rate3 Up to 220,000 points/s, point cloud density increases with time
Typical Noise4 •0.3mm@0.4mdistance •35mm@5mdistance •0.75mm@1mdistance •100mm@10mdistance • 10 mm @ 3 m distance
Lighting conditions5 Full daylight, 10,000-45,000 lux (reduced performance in direct sunlight)
Light source Integrated LED flash
Scan volume 39.5 m3 @ max range 5 m
Typical field of view (HxW) •420mmx550mm@0.5m •2740mmx3160mm@3m •930mmx1170mm@1m •3600mmx4160mm@4m •1800mmx2160mm@2m •4470mmx5150mm@5m
Exposure time 0.1 ms – 7 ms (autoexposure)
Texture color 24 bit
Dimensions 285 mm x 256 mm x 130 mm
Connectivity HDMI, USB 3.0, WiFi
Weight 1.48 kg
IP rating IP 52
Compensation Onsite – with supplied compensation plate
Op temperature range 0 – 40° C
Op humidity range Non-condensing
Eye Safety Class 1 Laser
Wavelength 798-816 nm

1 1 sigma standard deviation measured on reference scales of lengths between 0.3 m and 1 m, in 1 m distance, for a lateral scanner movement of 1 m, using targets for distance measurement | 2 Typical error at measured distances | 3 Point density depends on scanned surface and lighting conditions | 4 RMS | 5 Limited range and point density in sunlight
* Dust protection 5. Water protection 2: Protection against dripping water whilst device in standard idle position with sensor side facing downward.

Mobile PC Specifications
Microsoft Windows 10 pro, 64-Bit Intel® CoreTM i7 256 GB hard disc with 16 GB RAM
HDMI; USB 3.0 ports; WiFi
